DW L5-VET Laptop 4D Color Veterinary Doppler Ultrasound Machine Dog Canine Ultrasound Scanner

  • Brand: DW
  • Availability: In Stock
  • Our Price:$6295.99

  • 8th Anniversary Promotion Price:$5981.19

- +

Guaranty: 12 Months Warranty

Shipping: Free Shipping Over $49!

DW L5-VET Laptop 4D Color Veterinary Doppler Ultrasound Machine Dog Canine Ultrasound Scanner



Description:
It is a hand-carried color Doppler veterinary ultrasound system that allows veterinarians to diagnose anywhere and anytime with confidence

Features:
1.15 inch HD LED
2.Based on the Windows 7 platform, easy to upgrade the ultrasound system.
3.Backlight control panel
4.Dynamic range:0-160dB
5.Language:Chinese, English, Spanish, French, Russian, Arabic, Vietnamese, Portuguese, Indonesian, German, Persian and Thai
6.VET dedicated software:Expert veterinary preset,measurement and body mark Built-in high capacity lithium
7.Battery,battery life≥2.5 hours
8.One key intelligent optimization
9.Equipped with SSD, make the storage safer and more reliable.Built-in 60G solid state drive.
10.CN/EN/FR/SP/PT/language support.
11.Application:canine, feline, equine, bovine, ovine and other animals in theclinical abdomen, chest, heart, tendon, small organs, reproduction system, fetal and other examination
12.24 months warranty



Display 15 inch LED medical display
Probe connector Single 1
Operation interface English (more languages as option)
Display mode B,B+B,4B,B+M,M,C,PW,CW,4D,B/C,B/C/PW,B/PW
Focus 4 segments
Body mark ≥57
Image processing Up/Down, Left/Right, Angular variation, Reverse
Measurement Distance, circumference, area, volume, heart rate, diameter stenosis rate, area stenosis rate, angle, rhythm, speed.
Application canine,feline,equine,bovine,ovine and other animals in theclinical abdomen,chest,heart, tendon,small organs,reproduction system,fetal and other examination
Character display Date, time, name, sex, age, doctor, hospital, annotation (full screen character editing)
Cine loop ≥ 1200 frames, continuous playback or view one by one.
Storage Probe parameter, cine loop, measuring result, report can be saved and transferred to external storage device
Gray scale 256 levels
Puncture guide Available
Gravel positioning Available
Dynamic range 0-270dB
TGC control 8 segments
Pre-processing Variable aperture, dynamic apodization, dynamic digital filtering, multi-beam parallel processing technology, THI and so on.
Post-processing Dynamic range 0-270DB, black and white afterglow 0-7, smoothing 0-7, gray curve 1-16, frame correlation, SHI, sound power, wall filter, cumulative number, baseline adjustment, sampling frame adjustment, spectral sampling volume, spectral sampling volume angle, the PRF (pulse repetition frequency) and so on.
Blind zone ≤4mm
Max display depth 320mm
Geometric accuracy horizontal ≤ 5%, vertical ≤ 5%
Resolution lateral ≤ 2mm, axial ≤ 1mm
External interface Video, USB, DICOM 3.0
Display magnification 16 kinds
Frame rate 5-1016fps
Scanning range 5% - 100%
Gain adjustment Overall gain: 0 ~ 100%, PW gain: 0-15, CFM gain: 0-15
Image optimization 6 level adjustable
Smoothing 8 level adjustable
Edge enhancement 8 level adjustable
PRF 16 level adjustable
Gray scale curve 16 level adjustable
Acoustical power 15 level adjustable
Weight NW: 6.3kg         GW: 15kg
Packing size 60*50*27cm



Probe frequency range:

3.5MHZ convex probe: 2.0, 3.0, 3.5, 4.0, 5.5Mhz

6.5MHZ trans-vaginal Probe: 5.0, 6.0, 6.5, 7.5, 9.0Mhz

3.0MHZ Phased array probe: 2.0, 3.0, 3.5, 4.0, 5.0Mhz

7.5MHZ High frequency Linear Probe: 6.0, 6.5, 7.5, 10.0, 12.0Mhz

Volume probe: 2.0, 3.0, 3.5, 4.0, 5.5Mhz

Micro-convex probe R11: 2.0, 3.0, 3.5, 4.0, 5.5, 6.5, 7.5, 10.0 Mhz

Micro-convex probe R20: 5.0, 6.0, 6.5, 7.5, 9.0Mhz
